1 |
Rated voltage |
KV |
1.0/1.0 AC / 1.5kV DC |
1.0/1.0 AC / 1.5kV DC |
|
2 |
No. x Nominal conductor size |
No x mm* |
1 x 4 |
1 x 6 |
|
3 |
Approx. conductor diameter |
MM |
2.52 |
3.3 |
|
4 |
Nominal thickness of insulation |
MM |
0.7 |
0.7 |
|
5 |
Nominal thickness of Jacket |
MM |
0.8 |
0.8 |
|
6 |
Approx. overall cable diameter |
MM |
5.6 |
6.4 |
|
7 |
Approximate net weight |
KG/KM |
65.1 |
86.4
|
|
8
|
Applicable standard |
|
BS EN 50618 | IEC 62930 |
BS EN 50618 | IEC 62930 |
